Zoeller 161-0001 Flow-Mate M161 Effluent Sump Pump 1/2 HP 115V Auto

Zoeller Flow-Mate M161 (161-0001) For septic tanks, low-pressure pipes (LPP), and enhanced flow STEP systems. The 160 Series consists of top-of-the-line solutions designed to offer the best performance and reliability for various commercial applications.

Specs:

• Motor: 1/2 HP, 115 V
• Phase: 1
• RPM: 3450 RPM
• Type: Permanent split capacitor
• Insulation: Class B
• Amps: 2.4 - 15.5
• Operation: Automatic
• Discharge Size: 1-1/2" NPT
• Solids Handling: 3/4" (19 mm) spherical solids
• Cord Length: 20' (6 m) standard, UL listed, 3-wire cord and plug
• Max Head: 86.5' (26 m)
• Max Flow Rate: 100 GPM (379 LPM)
• Max Operating Temp: 130°F (54°C)
• Cap, Base, Motor Housing and Pump Housing all made of cast iron
• Impeller Type: Non-clogging vortex
• Impeller: Bronze

Features:

• Durable, cast iron constructed switch case, base, motor and pump housing
• Cast iron Class 25-30 (25,000X tensile strength)
• Impeller – bronze class 85-5-5-5
• Corrosion-resistant, powder coated epoxy finish
• Oil-filled, hermetically-sealed, automatic reset thermal overload protected (1 Ph only) motor
• Upper and lower ball bearing running in bath of oil
• Carbon and ceramic shaft seal
• SAE 1117 carbon steel motor shaft (single seal models only)
• Maximum temperature for effluent or dewatering: 130°F (54°C) (E/D: 140°F / 60°C)
• Major width: 12-3/4" (32 cm)
• Major height: 19-5/16" (49 cm)
• No screens to clog
• Neoprene square ring and gasket
• Stainless steel screws, bolts, float rod, handle, guard, arm and seal assembly
• Passes 3/4" (19 mm) spherical solids
• 1-1/2" NPT discharge with 2" or 3" flange available
• Automatic units available with float-operated, submersible, 2-pole mechanical switch
• On: point 14-3/4" (37.5 cm)
• Off: point 5" (12.7 cm)
• 100% of units are computerized tested
• 1 year limited warranty

Note: This item ships LTL freight.
